Wide Diameter Cable Ramp Rubber Wedge Module – Black
| Product Code: | WHHCR26 |
|---|---|
| Dimensions: | 1200 x 400 x 155mm (max) |
| Weight: | 42 kg |
The Wide Diameter Cable Ramp Rubber Wedge Module - Black is part of our modular ramp system. The system protects cables and hoses by enabling pedestrian and vehicular traffic to cross safely. The ramp is finished in black, features a ridged surface for enhanced grip and can be linked with other ramp modules to create a wider bridge.
Wide Diameter Cable Ramp Rubber Wedge Module technical specifications
The ramp measures 1200 mm x 400 mm x 155mm and has a 44-tonne maximum loading capacity. Depending on which steel ramp top is used in the system, it can accommodate hoses ranging from 140 mm to 180 mm in diameter. Combined with other components in the modular system, a ramp measuring 3,750 mm in length can be created, enabling most cars to traverse without beaching.
For more information on our Wide-Diameter Cable Ramp Rubber Wedge Module in Black, contact our expert team at 0117 954 1117 or email info@provincialrubber.co.uk.
| Max Load | 44 Tonnes |
|---|---|
| Channel | 210 x 150mm |
